Product Features All Mattson machines components adopt the qualified materials. 100% quality check and durable testing. Affordable Price: Large scale production and well trained workers reduce cost greatly, you can get the machine with affordable price which will great improve the working...
Product Features
DIMENSIONS | |||
A. Angle of Departure | 22° | K. Length with Standard Bucket | 2605 mm |
B. Carry Position | 176 mm | L. Operating Height | 2623 mm |
C. Dump Angle @ Maximum Height | 37° | M. Rollback @ carry Position | 20° |
D. Dump Height with Standard Bucket | 1279 mm | N. Rollback Fully Raised @ Maximum Height | 93°
|
E. Dump Reach @ Maximum Height | 834 mm | ||
F. Ground Clearance | 193 mm | O. Ground Contact Length | 775 mm |
G. Ground Clearance-under platform | 185 mm | P. Turning Radius with Standard Bucket | 1621 mm |
H. Height to Bucket Hinge Pin | 1867 mm | Q. Width (23×8.5-12 tires) | 1080 mm |
I. Height | 1297 mm | R. Wheel Tread (over 23×8.5-12 tires) | 856 mm |
J. Length without Attachment | 1969 mm | S. Width with 36" Bucket | 1250 mm |
PERFORMANCE | |
Operating Capacity (35%) | 262 kg |
Operating Capacity (50%) | 374 kg |
Tipping Capacity | 748 kg |
Max. Travel Speed | 10.8 km/h |
Machine Weight (no attachment) | 935 kg |
ENGINE | |
Make/Model | Kubota D1105 |
Fuel/Cooling | Diesel/Liquid |
Horsepower (SAE Gross) | 18.5 kW |
Maximum Governed RPM | 3000 RPM |
Torque @ 2200 RPM (SAE Net) | 71.5 Nm |
Number of Cylinders | 3 |
All Mattson machines components adopt the qualified materials. 100% quality check and durable testing.
Affordable Price:
Large scale production and well trained workers reduce cost greatly, you can get the machine with affordable price which will great improve the working efficiency.
Professional Team:
15 years experience, rich professional skills, all Mattson staff will stand by you, reply your inquiry and solve problem, no matter pre-sales or after-sales.
Fast Delivery Time:
Our company has advanced production equipment, 15,000 square meters factory, 185 skilled workers. Your urgent orders can be ready in just 1 week.
Customer Service:
Professional service team will let you feel easy to communicate with Mattson, any help, just a call, we will help no matter what time ,no matter where you are.
