All Wheel Steer Skid Steer

All Wheel Steer Skid Steer

Product Description

Inquire Now

Add To Cart

Product Description

All wheel steer skid steer is one of the most popular mini construction machinery in the world. Relying on its flexible steer, compact body and replaceable mulitifunctional tools, it can finish all kinds of comprehensive construction demand easily. The apperance, heightlifting, weightlifting and driving comfort are all the top-notch loader in the world.

Always supply the high quality machine and Variously styles can meet the customers' all kinds of request.

Product Specifications

ITEMS	DIMENSIONS		ITEMS	DIMENSIONS
A	Angle of Departure	22°	L	Operating Height	2623 mm
B	Carry Position	176 mm	M	Rollback @ carry Position	20°
C	DumpAngle @ Maximum Height	37°	N	Rollback Fully Raised @ Maximum Height	93°
D	Dump Height with Standard Bucket	1279 mm	N	Rollback Fully Raised @ Maximum Height	93°
E	Dump Reach @ Maximum Height	834 mm	O	Wheel Base	775 mm
F	Ground Clearance	193mm	P	Turning Radius with Standard Bucket	1621 mm
G	Ground Clearance-under platform	185 mm	Q	Width 23×8.5-12	1080 mm
H	Height to Bucket Hinge Pin	1867 mm	Q	Width 23×8.5-12	1080 mm
I	Height	1297 mm	R	Wheel Tread 23×8.5-12	856 mm
J	Length without Attachment	1969 mm	R	Wheel Tread 23×8.5-12	856 mm
K	Length with Standard Bucket	2605 mm	S	Width with 36" Bucket	1250 mm

Product Advantages

1)Multi-function, High cost performance. With dozens of matching assistive devices, it is very easy operation, conveniet maintenance, and wide application.

2)Strong driving power: the engin power is from 25Hp to 50Hp, adopt the Kubota engine and Perkins engine and established a long-term partnership to ensure the machine is capable of working in a variety of envirement.

3)Perfect hydraulic system: Full hydraulic pilot control,hydraulic self-balancing.

4)Durable structure parts: All structure parts are with our own R&D, design and manufacturing by ourselves, which are beautiful and durable.Hydraulic oil tank, fuel tank and chassis combined as one, which maximizes the performance of the machine and makes the working arm and body to achieve the perfect combination.

5)The key components are all imported products.
